Ball siphon on suction side (underpressure) – transparent – OUTDOOR INSTALLATION

Condensate drain for HVAC systems for outdoor installation.
Applicable only on the suction (underpressure) side.
Maximum underpressure: 3500 Pa.
Material: UV-resistant / heat-resistant / freeze-proof (can expand, not equipped with heating tape).
Connection with rubber sleeve.
Connection (drain) diameter: DN40.
Self-filling siphon with ping-pong ball acting as non-return valve and removable screw cap for filling and cleaning.
The ping-pong ball prevents air suction when dry, allowing the siphon to fill automatically with the first condensate formation.
Transparent section for visual inspection of water discharge.
The siphon must always drain freely (do not connect directly and continuously to the wastewater system).
Horizontal installation is absolutely required to ensure proper sealing function of the ping-pong ball.

Siphon selection:

Product code	Zuigzijdig (geschikt voor buitenopstelling)
Category	Weger
Subcategory	Siphon

Adapter 40/1”

(Transition from condensate tray with 1” male thread to 40 mm siphon connection)
⚠️ Do not forget to order this adapter!
